Exam NSE4_FGT_AD-7.6 Topic 4 Question 40 Discussion

Actual exam question for Fortinet's NSE4_FGT_AD-7.6 exam
Question #: 40
Topic #: 4
Refer to the exhibits. The exhibits show a diagram of a FortiGate device connected to the network, as well as the IP pool configuration and firewall policy objects.

The WAN (port2) interface has the IP address 100.65.0.101/24. The LAN (port4) interface has the IP address 10.0.11.254/24. Which IP address will be used to source NAT (SNAT) the traffic, if the user on HQ-PC-1 (10.0.11.50) pings the IP address of BR-FGT (100.65.1.111)

Suggested Answer: C Vote an answer

The ping traffic policy uses the IP pool named SNAT-Remote1, which has the external IP range
100.65.0.99. Therefore, traffic matching this policy (ping from HQ-PC-1 to BR1-FGT) will use
100.65.0.99 for source NAT.

by Roberta at Jun 09, 2026, 12:34 AM
